BL32 Series Inner Rotor Brushless Motor

BL3245

•Axial and radial clearance control: It can better deal with the shock force of the pump and extend the life of the motor；

•Spring-like structure：Can better solve the motor abnormal sound, reduce the axial clearance；

•Latch protection：When the controller detects that the motor is blocked, the output is shut down and the motor stops running；

Data download Back to list

Specifications

Input Voltage	24V DC
Dimensions(mm)	Φ32x73
Shaft Diameter(mm)	Ф3
No Load Speed(rpm)	4400
No Load Current(A)	0.125
Nominal Speed(rpm)	3450
Nominal Torque(Nm)	0.032
Nominal Current(A)	0.7
Stall Torque(Nm)	0.2
Stall Current(A)	2.33
Maximum Output Power(W)	13.6
Maximum Efficiency(%)	63
Life（Typical）	10000hrs
Weight(g)	104
Operating Temperature Range(°C)	-20 to 50
Storage Temperature Range(°C)	-30 to 70

Performance Data

Outline Drawing

Performance Curves

Application

: Medical pump motor
With the development of science and technology and the improvement of medical level, the function of medical equipment will be more and more advanced, and its product structure will be adjusted continuously, and its function will be more diversified. The BL32 brushless motor developed by our company for this purpose has the characteristic of ‘small and precise’, and can be applied in many kinds of medical devices.
+
