•Compact design、Lightweight、Long service life；
• High power density and torque、High cost performance and high efficiency；
• High structural strength, strong and durable、 High reliability、Low vibration and noise；
Data download Back to list
| Input Voltage | 58V DC |
| Dimensions(mm) | Φ35×77.5 |
| Shaft Diameter(mm) | Ф6 |
| No Load Speed(rpm) | 27708 |
| No Load Current(A) | 1.41 |
| Rated Torque(Nm) | 25553 |
| Rated Torque (rpm) | 0.27 |
| Rated Current(A) | 14.7 |
| Stall Torque(Nm) | 3.771 |
| Stall Current(A) | 185 |
| Maximum Output Power(W) | 2713 |
| Maximum Efficiency(%) | 83.78 |
| Life（Typical） | 200hrs |
| Weight(g) | 175 |
| Operating Temperature Range(°C) | -15 to 45 |
| Storage Temperature Range(°C) | -15 to 45 |
A high-pressure sprayer is a device widely used in various fields such as agriculture, landscaping, sanitation, and disinfection and epidemic prevention. It is primarily used to atomize liquids and spray them evenly to achieve purposes such as applying pesticides, cleaning, and disinfection.
+
The garden tool leaf blower is an efficient cleaning tool, mainly used for cleaning up in gardens, farms, nurseries and other places. It quickly blows away fallen leaves, dust, weeds and other debris through strong wind power, significantly improving cleaning efficiency and reducing manual labor intensity.
