•Compact design、Lightweight、Long service life；
• High power density and torque、High cost performance and high efficiency；
• High structural strength, strong and durable、 High reliability、Low vibration and noise；
Data download Back to list
| Input Voltage | 18V DC |
| Dimensions(mm) | Φ35x51.7L |
| Shaft Diameter(mm) | Ф4 |
| No Load Speed(rpm) | 22134 |
| No Load Current(A) | 1.93 |
| Rated Torque(Nm) | 0.17 |
| Rated Torque (rpm) | 19183 |
| Rated Current(A) | 24.32 |
| Stall Torque(Nm) | 1.294 |
| Stall Current(A) | 169 |
| Maximum Output Power(W) | 747 |
| Maximum Efficiency(%) | 77.37 |
| Life（Typical） | 100hrs |
| Weight(g) | 108 |
| Operating Temperature Range(°C) | -15 to 45 |
| Storage Temperature Range(°C) | -15 to 45 |
String trimmer is a garden tool specialized in trimming hedges, shrubs, tea trees and other plants, widely used in parks, gardens, roadside hedges and tea gardens and other scenes. String trimmer with its efficient and convenient characteristics, become an indispensable tool in modern garden and agricultural production, matching the right motor can significantly improve the working efficiency, while ensuring the quality of pruning.
+
Intelligent mowing robot is a comprehensive robot system integrating environment sensing, path dynamic planning, behavior control and other functions. Topband motor for lawn mowing robot motor long-term facing five core pain points: insufficient torque leads to cutting high-density lawn efficiency, high noise and vibration affect user experience and equipment life, poor environmental adaptability caused by rain sand intrusion failure, high energy consumption constraints on endurance, the launch of the AE107 series of outer rotor BLDC Motor solutions, by virtue of its high efficiency, high reliability, low noise and other advantages, to promote the mowing robot to high efficiency and durability in the direction of environment-friendly iteration. With its advantages of high efficiency, high reliability and low noise, the solution is introduced to promote the iteration of lawn mowing robots in the direction of high efficiency, durability and environmental friendly.
