•Large torque，good heat dissipation, high efficiency, long endurance；
•High structural strength, strong and durable, high reliability, low vibration, low noise；
Data download Back to list
| Input Voltage |
24V DC |
|
Dimensions(mm) |
Ф80x130L |
|
Shaft Diameter(mm) |
Ф10 |
|
No Load Speed(rpm) |
4800 |
|
No Load Current(A) |
0.9 |
|
Nominal Speed(rpm) |
3600 |
|
Nominal Torque(Nm) |
1.35 |
|
Nominal Current(A) |
26 |
|
Stall Torque(Nm) |
1.501 |
|
Stall Current(A) |
28.37 |
|
Maximum Output Power(W) |
541.4 |
|
Maximum Efficiency(%) |
87.08 |
|
Life（Typical） |
20000hrs |
| Weight(g) |
2030 |
|
Operating Temperature Range(°C) |
-20 to 55 |
|
Storage Temperature Range(°C) |
-40 to 70 |
Intelligent rail trolley logistics transmission system is a computer-controlled system for the integrated transmission of medical items, using extremely reliable distributed system control technology, through specific horizontal and vertical tracks located in the hospital's various clinical departments and various wards of the logistics transmission site, by loading trolleys along the track to achieve three-dimensional, point-to-point transmission of items between clinical departments, wards, medical and technical departments, and the hospital management department.
