•Small groove torque，good heat dissipation, high efficiency, long endurance；
•High structural strength, strong and durable, high reliability, low vibration, low noise；
Data download Back to list
| Input Voltage |
27.2V DC |
|
Dimensions(mm) |
102x102x155.3 |
|
Shaft Diameter(mm) |
Ф12 |
|
No Load Speed(rpm) |
4800 |
|
No Load Current(A) |
0.95 |
|
Nominal Speed(rpm) |
3900 |
|
Nominal Torque(Nm) |
1.02 |
|
Nominal Current(A) |
17.5 |
|
Stall Torque(Nm) |
5.176 |
|
Stall Current(A) |
83.34 |
|
Maximum Output Power(W) |
661.6 |
|
Maximum Efficiency(%) |
92.06 |
|
Life（Typical） |
20000hrs |
| Weight(g) |
3424 |
|
Operating Temperature Range(°C) |
-40 to 95 |
|
Storage Temperature Range(°C) |
-40 to 95 |
As the wave of New Energy Vehicles (NEVs) sweeps across the globe, Thermal Management Systems (TMS) are becoming increasingly important as a key element in improving the range and safety of NEVs. In this rapidly developing field, liquid cooling solutions have become the backbone of thermal management systems for NEVs.
