BL5320 Series Inner Rotor Brushless Motor

BL5320

•Can be closed design, to deal with the water dust more working environment；

•Optional split design, easy to disassemble and assemble, easy to maintain；

•Lightweight design，Optional Integrated control scheme；

Specifications

Input Voltage	18V DC
Dimensions(mm)	Φ53x92.9L
Shaft Diameter(mm)	Ф8
No Load Speed(rpm)	22500
No Load Current(A)	6.5
Nominal Speed(rpm)	17500
Nominal Torque(Nm)	0.43
Nominal Current(A)	64
Stall Torque(Nm)	1.8
Stall Current(A)	221
Maximum Output Power(W)	1066
Maximum Efficiency(%)	79.5
Life（Typical）	300hrs
Weight(g)	355
Operating Temperature Range(°C)	-10 to 70
Storage Temperature Range(°C)	-20 to 70

Performance Data

Outline Drawing

Performance Curves

Application

: Electric Drill Solution
