•The multi-pole and multi-slot substructure is adopted, and the triangle is connected in parallel；
•Using rare earth magnetic steel, small size, high speed, good heat dissipation, high efficiency, long endurance；
•High structural strength, strong and durable, high reliability, low vibration, low noise；
Data download Back to list
| Input Voltage |
18V DC |
|
Dimensions(mm) |
Φ48x28 |
|
Shaft Diameter(mm) |
Ф5 |
|
No Load Speed(rpm) |
22282 |
|
No Load Current(A) |
4.79 |
|
Stall Torque(Nm) |
1.681 |
|
Stall Current(A) |
204.4 |
|
Maximum Output Power(W) |
980.88 |
|
Maximum Efficiency(%) |
80.21 |
|
Life（Typical） |
500hrs |
| Weight(g) |
240 |
|
Operating Temperature Range(°C) |
-10 to 70 |
|
Storage Temperature Range(°C) |
-20 to 70 |
In recent years, the power tools industry has shown rapid development, in the domestic power tools market, the number of sales of domestic power tools has accounted for 90% of the total sales, while a variety of imported brand-name products accounted for only 10% of the market share. In the foreign power tools market, the proportion of China's manufacturing continues to expand, China has become the world's leading exporter of power tools and global power tools production base, the industry has great potential for development.
