BL4010 Series Inner Rotor Brushless Motor

BL4010

•Unique design and compact structure；

•High rotational speed, making it suitable for applications requiring high-speed operation；

•Fast response，High torque, efficiency and power density；

Data download Back to list

Specifications

Input Voltage	19.6V DC	25.4V DC
Dimensions(mm)	Φ60x79.2	Φ60x79.2
Shaft Diameter(mm)	Φ4	Φ4
No Load Speed(rpm)	120000	155000
No Load Current(A)	9.5	9.5
Nominal Speed(rpm)	70000	85000
Nominal Torque(Nm)	0.018	0.016
Nominal Current(A)	16.59	13.41
Stall Torque(Nm)	2	2
Stall Current(A)	30	30
Maximum Output Power(W)	352.5	362.5
Maximum Efficiency(%)	45.2	44.34
Torque at Max Eff.(Nm)	0.2	0.18
Speed at Max Eff.(rpm)	66000	75000
Life（Typical）	≥500 hrs	≥500 hrs
Weight(g)	230	230
Operating Temperature Range(°C)	-10 to 40	-10 to 40
Storage Temperature Range(°C)	-40 to 50	-40 to 50
