•Small size and Light weight；
• Using rare earth magnetic steel, high power density, high efficiency；
• The rotor is light and the braking time is short；
Data download Back to list
|
输入电压 |
15伏直流电 |
24V直流 |
|
尺寸（毫米） |
φ48x27.2 |
φ48x27.2 |
|
轴径(mm) |
F6 |
F6 |
|
空载转速(rpm) |
891 |
890 |
|
空载电流(A) |
0.168 |
0.105 |
|
额定转速（rpm） |
695 |
691 |
|
标称扭矩（Nm） |
0.04 |
0.04 |
|
标称电流（A） |
0.42 |
0.26 |
|
堵转扭矩(Nm) |
0.181 |
0.179 |
|
堵转电流(A) |
1.3 |
0.8 |
|
最大输出功率（W） |
4.23 |
4.17 |
|
最大效率(%) |
47.11 |
46.78 |
|
最大效率扭矩（Nm） |
0.048 |
0.048 |
|
最大效率转速（rpm） |
655 |
653 |
|
寿命（典型值） |
20:00 |
20:00 |
| 重量（克） |
40 |
40 |
|
工作温度范围（°C） |
-10 至 70 |
-10 至 70 |
|
储存温度范围（℃） |
-20 至 70 |
-20 至 70 |
With the development of smart home, ‘electric curtains’ gradually into the high-end hotels, high-end home life, a key to open and close, voice control of the senior sense, in the daily busy life, to bring people a comfortable and convenient feeling. Become a standard configuration of many five-star hotels, villas, well-decorated flats.
+
With the development of science and technology and the improvement of medical level, the function of medical equipment will be more and more advanced, and its product structure will be adjusted continuously, and its function will be more diversified. The BL32 brushless motor developed by our company for this purpose has the characteristic of ‘small and precise’, and can be applied in many kinds of medical devices.
