AEGE1934

Low gear backlash torque, high torque, long lifespan, high-precision control

Compact and high-powered

Data download Back to list
Specifications
Input Voltage
 12V DC
Dimensions(mm)
 Φ19*16.5H
Shaft Diameter(mm)
 Ф19
No load speed(rpm)
 96.9
No load current(A)
 0.12
Nominal Speed(rpm)
 75.59
Nominal Torque(Nm)
 /
Nominal Current(A)
 0.388
Stall Torque(Nm)
 979
Stall Current (A)
 1.376
Maximum Output Power(W)
 16.6
Maximum Efficiency(%)
 50
Life（Typical）
 /
Weight(g) 19.5
Operating Temperature Range(°C)
 /
Storage Temperature Range(°C)
 /
Performance Data
Item No load Stall Max eff. Max power
Current(A) 0.17 1.376 0.083 /
Efficiency(%) / / 50 /
Output power(W) / / / 16.6
Speed(rpm) 96.9 / 75.95 /
Torque（Nm） / / / /

Outline Drawing
Performance Curves
Application
